Detailed descriptions
16.1 Motherboard
SIMATIC IPC647C
148 Operating Instructions, 12/2010, A5E02669337-02
16.1.2 Technical features of the motherboard
Component / interface Description Parameters
Chipset Single chipset
 Mobile Intel® 5 chipset QM57 Express
(Platform Controller Hub)
BIOS Update by means of
software
 Insyde modified by Siemens
CPU Intel® Core™ i
 VT and multimedia support
 Turbo Boost and AMT, depending on CPU
 On Board cache with 3M/4M depending on
CPU
Memory 2 DIMM module slots,
max. 4 GB per module
 Data width of 64/72 bits (without ECC / with
ECC)
 3.3 V
 DDR3-SDRAM in accordance with PC3-8500
specification
 1 to 2 Gbit chip size on the module
 1066MT/sec transfer rate
 Variable from 1 GB to 8 GB / DIMM
 With and without ECC
Graphics Integrated in chipset
 Mobile CPU with integrated "Hi-K process
Graphics" Graphics Controller and
 Mobile Intel® QM57 Express (Platform Controll
er Hub)
– VGA:
2560x1600/32-bit color depth/120 Hz to
2560x1600 at 60 Hz/32-bit color depth
– DVI-I:
2048x1152/32-bit color depth/60 Hz
 Graphics memory:
Up to 1.7 GB, used in system memory, 32 MB
reserved.
Hard disk
4
Various SATA modes,
AHCI, RAID 0, 1 and
RAID 5 can be set
 Compatible to SATA 150 / 300
 Supports NCQ (Native Command Queuing)
DVD ROM
4
DVD ROM/CD RW
4
SATA interface
 Compatible to SATA 150 / 300
Floppy
4
FD drive interface
 1.44 MB
Keyboard PS/2 keyboard
interface
 Standard
Mouse PS/2 mouse interface
 Standard
Serial COM1/9-pin
COM2/9-pin
 V.24
Parallel Standard, bi-directional,
EPP and ECP mode
 25-pin D-sub
