Technical specifications
14.2 Power requirements of components (maximum values)
SIMATIC IPC647C
140 Operating Instructions, 12/2010, A5E02669337-02
Note
Check the
8ESD guidelines (Page 3221).
The specifications apply only when:
The devices is in correct working order.
The fan cover and filter mat are installed.
The front door is closed.
14.2 Power requirements of components (maximum values)
Base system
Voltage
Component
+5 V +3.3 V +12 V -5 V -12 V 5 Vaux
Motherboard core i processor with cooling 4 A 2.3 A 3.0 A 0.03 A 0.3 A
Front fan 1 0.4 A
Front fan 2 0.4 A
Base system (dual core) 4 A 1 A 4 A 0 A 0.03 A 0.3 A
HDD
1
0.5 A 0.7 A
DVD Burner
1
0.8 A
Single currents (max. permissible) 30 A
2
28 A
2
15 A 0.5 A 0.5 A 2 A
Total power consumption, permissible 160 W
Efficiency of the power supply Approx. 80% (230 V AC) / approx. 75% (120 V AC)
1
based on the selected device configuration
2
The accumulated power of the + 5 V and + 3.3 V may not exceed 190 W.
Typical power values
Component Current input
(AC-SV, U=230 V)
Power consumption
Base device 0.2 A 45 W
Hard disk drive 1 x 3.5" 0.04 A 9 W
Hard disk drives 2 x 3.5" 0.08 A 18 W
DVD burner drive 0.02 A 4 W
