Page #118 background imageLoading...
Page #118 background image
Operator controls and operating modes of the CPU 410-5H
7.3 Self-test
CPU 410-5H Process Automation
118 System Manual, 09/2014, A5E31622160-AB
Hardware fault with one-sided call of OB 121, checksum error, second occurrence
A CPU 410–5H reacts to a second occurrence of a hardware fault with a one-sided call of
OB 121 and to checksum errors as set out in the table below, based on the various operating
modes of the CPU 410.
Table 7- 6 Hardware fault with one-sided call of OB 121, checksum error, second occurrence
Error
CPU in stand-alone operation/single mode
CPU in redundant operation
Hardware fault with one-
sided call of OB 121
OB 121 is executed The faulty CPU switches to ERROR-SEARCH
operating state. The fault-tolerant system
switches to single mode.
Checksum errors The CPU enters the DEFECTIVE state if two
errors occur within two successive test cycles
(configure the length of the test cycle in
HW Config).
The CPU enters the DEFECTIVE state if a
second error triggered by the first error event
occurs in ERROR-SEARCH mode.
If a second checksum error occurs in solo or stand-alone operation after twice the test cycle
time has expired, the CPU reacts as it did on the first occurrence of the error. If a second
error (hardware fault with one-sided call of OB 121, checksum error) occurs in redundant
operation when troubleshooting is finished, the CPU reacts as it did on the first occurrence of
the error.
Multiple-bit errors
If a multiple-bit error is detected during redundant operation of a fault-tolerant system, the
CPU switches to ERROR-SEARCH operating state. When troubleshooting is finished, the
CPU can be linked up and updated again, and resume redundant operation. If there is no
error in the CPU, it switches to RUN and becomes master. The cause of the error is signaled
by the call of OB 84.
There are some rare cases in which multiple-bit and single-bit errors can occur due to very
challenging ambient conditions. If they occur only once, they do not interfere with the
hardware. If bit errors occur frequently, however, replace the hardware.
Single-bit errors
Single-bit errors are also detected and eliminated outside the self-test. The CPU calls OB 84
after elimination of the error.
