Link-up and update
8.3 Time monitoring
CPU 410-5H Process Automation
126 System Manual, 09/2014, A5E31622160-AB
Determining the monitoring times
Calculation using STEP 7 or formulas
STEP 7 automatically calculates the monitoring times listed below for each new
configuration. You can also calculate these times using the formulas and procedures
described below. They are equivalent to the formulas provided in STEP 7.
● Maximum cycle time extension
● Maximum communication delay
● Maximum inhibit time for priority classes
● Minimum I/O retention time
You can also start automatic calculation of monitoring times with Properties CPU > H
Parameters in HW Config.
times determined by STEP 7 or by using formulas merely represent
These times are based on a fault-tolerant system with two communication peers and an
average communication load.
Your system profile may differ considerably from those scenarios, therefore the following
rules must be observed.
● A high communication load can significantly increase cycle time.
● Any modification of the system in operation may lead to a significant increase in cycle
times.
● Any increase in the number of programs executed in priority classes > 15 (in particular
processing of communication blocks) increases the delay in communication and extends
the cycle time.
● You can even undercut the calculated monitoring times in small plants with high-
performance requirements.
