Siemens SIMATIC PCS 7 CPU 410-5H User Manual

CPU 410-5H Process Automation
System Manual, 09/2014, A5E31622160-AB
335
Function and communication modules that can be
used in a redundant configuration
B
A complete list of all modules approved for PCS 7 V8.1 is available in the technical
documentation of SIMATIC PCS 7 at the following address: SIMATIC PCS 7 technical
documentation (http://www.automation.siemens.com/mcms/industrial-automation-systems-
simatic/en/manual-overview/tech-doc-pcs7/Pages/Default.aspx)
In
redundant configuration
you can use the following function modules (FM) and
communication processors (CP) with a CPU 410-5H.
Note
There may be further restriction for individual modules. Refer to the information in the
corresponding product information and FAQ, or in SIMATIC NET News.
FMs and CPs which can be used centrally
Module
Article No.
Release
One-sided
Redundant
Function module FM 458-1 DP 6DD 1607-0AA2 As of firmware 2.0.0 Yes No
Communication processor
CP 443-1 Multi (Industrial Ethernet
ISO and TCP/IP, 2-port switch)
Without PROFINET IO and
PROFINET CBA
6GK7 443-1EX20-0XE0 As of product version 1
As of firmware V2.1
Yes Yes
6GK7 443–1EX30–0XE0 As of product version 1
As of firmware V3.0
Yes Yes
Communication processor CP 443-
1 Multi (Industrial Ethernet ISO and
TCP/IP, 4-port switch, gigabit port)
6GK7 443–1GX30–0XE0 As of product version 1
As of firmware V3.0
Yes Yes
Communication processor
CP 443-5 Extended (PROFIBUS
DPV1)
1) 2)
6GK7 443-5DX04-0XE0 As of product version 1
As of firmware V6.0
Yes Yes
6GK7 443-5DX05-0XE0 As of product version 1
As of firmware V7.1
Yes Yes
1)
Only these modules should be used as external master interfaces on the PROFIBUS DP.
2)
These modules support DPV1 as external DP master interface module (complying with
IEC 61158/EN 50170).
