System modifications during redundant operation
10.5 Editing CPU parameters
CPU 410-5H Process Automation
174 System Manual, 09/2014, A5E31622160-AB
10.5
Editing CPU parameters
10.5.1
Editing CPU parameters
Only certain CPU parameters (object properties) can be edited in operation. These are
highlighted in the screen forms by blue text. If you have set blue as the color for dialog box
text on the Windows Control Panel, the editable parameters are indicated in black
characters.
Note
If you edit any protected parameters, the system will reject any attempt to changeover to the
CPU containing those modified parameters. The event W#16#5966 is written to the
diagnostic buffer. and you will then have to restore the wrongly changed pa
rameters in the
parameter configuration to their last valid values.
Table 10- 1 Modifiable CPU parameters
Tab
Editable parameter
Startup
Monitoring time for signaling readiness by modules
Monitoring time for transferring parameters to modules
Cycle/clock memory
Cycle load due to communication
Memory
Local data for the individual priority classes
Time-of-day interrupts (for each time-of-
day interrupt OB)
"Active" checkbox
"Execution" list box
Starting date
Time
Watchdog interrupt (for each watchdog
interrupt OB)
Execution
Phase offset
Diagnostics/clock
Correction factor
Security Security level and password
H parameter
Test cycle time
Maximum cycle time extension
Maximum communication delay
Maximum inhibit time for priority classes > 15
Minimum I/O retention time
The selected new values should match both the currently loaded and the planned new user
program.
