Siemens UL 1066 User Manual

4 – 1
4 Packing and Lifting
4.1 Unpacking
Unpack the circuit breaker and inspect it for damage.
If the circuit breaker or cradle is to be installed at a later date:
they may only be stored and redispatched in the original packing.
4.2 Weights
NOTICE
Equipment Damage.
Placing the circuit breaker on its rear side may cause damage to the finger cluster assemblies.
When handling circuit breakers, do not place them on their rear side.
Frame Size
Weight
Draw-out circuit breaker
Fixed Mounted
Circuit Breaker
Cradle
Circuit Breaker
+ Cradle
3-pole 4-pole 4-pole 3-pole 4-pole 3-pole 4-pole
II 800 A 159 lb / 72 kg 210 lb / 95 kg 185 lb / 84 kg 112 lb / 51 kg 161 lb / 73 kg Only lift separately
II 1600 A 159 lb / 72 kg 210 lb / 95 kg 185 lb / 84 kg 112 lb / 51 kg 161 lb / 73 kg Only lift separately
II 2000 A 177 lb / 80 kg 227 lb / 103 kg 203 lb / 92 kg 128 lb / 58kg 181 lb / 82 kg Only lift separately
II 3200 A 209 lb / 95 kg 258 lb / 117 kg 229 lb / 104 kg 152 lb / 69 kg 212 lb / 96 kg Only lift separately
II Fused 227 lb / 103 kg not available not available 150 lb / 68 kg not available Only lift separately
III 260 lb / 118 kg 434 lb / 197 kg 375 lb / 170 kg 306 lb / 139 kg 410 lb / 186 kg Only lift separately
III Fuse
Carriage
225 lb / 102 kg not available not available 306 lb / 139 kg not available Only lift separately
