12.2 Installing the ready-to-close switch S20
Snap-in mounting
The connecting wires from the ready-to-close signaling switch must be connected to terminal X6 according to the wiring plan (page 8-3).
DANGER
Hazardous voltage.
Will cause death, serious personal injury, or equipment damage.
Turn off and lock out all power supplying this device before working on this device.
WARNING
High speed moving parts.
Can cause serious personal injury.
Discharge the closing spring before inspection and before carrying out any work on the circuit breaker.
Signaling switches Catalog No.
Ready-to-close signaling switch S20 WLRTCS
