12 – 6
12.4 Control switches - Connecting wires
(1) Cut-off switch S13 for remote reset
(2) Cut-off switch S14 for shunt trip F1  (page 11-4)
(3) Cut-off switch S15 for closing coil CC  (page 11-4)
(4) Motor disconnecting switch S12  (page 13-3)
12.5 Communication switches
 Signaling switches for BSS (page 9-55)
12.6 Connecting secondary wiring
 Circuit diagrams (page 8-4)
12.7 Updating the options label
NOTE
After installing additional components, mark the following data with a "x", using an indelible ink pen.
(1) (2) (3) (4)
3,0 x 0,6
Siemens Industry, Inc., Fort Worth, TX 76155 USA
Charging Motor
Remote Close Coil
X5-2 (+)
X5-1 (-)
X6-7 (+)
X6-8 (-)
240
250
VAC
VDC
120
125
VAC
VDC
240
250
VAC
VDC
120
125
VAC
VDC
VAC
VDC
120
125
VAC
VDC
1st Shunt Trip
UVR
2nd Shunt Trip
Remote Reset
X6-13 (-)
X6-14 (+)
X5-11 (-)
X5-12 (+)
X9-1 (-)
X9-2 (+)
X8-13 (-)
X8-14 (+)
Ready to Close Switch
X6-5
X6-6
240 VAC
4A
240 VAC
1st Shunt Trip Switch
X9-7
X9-8
240 VAC
240 VAC
UVR Switch
Open Fuse Switch
X9-10
X9-11
X9-5
X9-6
52a 1st Aux. SW. 52b
X6-3
X6-4
X6-11
X6-12
X6-1
X6-2
X6-9
X6-10
X5-5
X5-6
X5-9
X5-10
X5-3
X5-4
X5-7
X5-8
52a 2nd Aux. SW. 52b
240 VAC ,
Bell Alarm
240 VAC
5A
5A
X9-13
X9-14X9-12
3A
3A
Assembled in USA
10 A / 125 VDC , 0.5 A / 24 VDC , 3A
0131-FW
