9 – 91
9.2.4
Ex
ternal sensor
fo
r neutral conducto
r
(1)
V
ersion for copper bar
on s
witchgear side
(2)
Mounting brack
et
(3)
Screw M6 with washers and n
ut
(4)
V
ersion with copper connectors
(5)
Connector P2
(6)
Connector P1
Dimension dr
awi
ngs
(page
7-18)
T
erm
inal assignment
Remov
e bridge X8.9
- X8.10
This arrangemen
t ensures the same directi
on of the current flow
f
or the circuit break
er and the e
xternal neutral sensor
.
(1)
(2)
(3)
(4)
(5)
(6)
Main conducting path
0377_nu
S1
P1
P2
S2
X8.10
X8.9
1
2
3
4
5
6
External
N sensor
170
172
