6 – 3
6.1.3 Unlocking the racking handle / withdrawing the racking handle
1 OPEN circuit breaker
2 Push the crank inwards
3 Pull out the handle
4 Lift and hold the control lever
5 Pull out the crank
6.1.4 Racking circuit breaker into connected position
6.1.5 Inserting racking handle
NOTICE
Racking Handle Damage.
Turning the racking handle beyond the stop will cause damage to the racking mechanism.
When the stop is reached, rotate the racking handle counter-clockwise until it can be pushed inwards.
5
4
Hold
3
2
1
Position indicator
blue
green
red
Stop
1
2
3
4
