7 – 10
7.5 Frame size III, fixed-mounted version
press-in nut M 10
(metric thread)
35.04 [890.0]
17.77 [451.5]
20.67 [525.0]
35.98 [914.0]
required space for aux. connectors
including wire-channel
breaker front cover
5.91 [150.0]
0.79 [20.0]
1.77 [45.0]
11.28 [286.5]
1.75 [44.4]
1.75 [44.4]
1.75 [44.4]
7.50 [190.5]
3.75 [95.2]
0.55 [ 14.0]
1.75 [44.4]
1.20 [30.5]
5.00 [127.1]
required space for aux. connectors
including wire-channel
4.25 [108.0] large door cut-out [with edge protector)
4.45 [113.0] door cut-out, middle escutcheon visible
4.61 [117.0] minimal door cut-out, only center escutcheon visible
Fixed-mounted versions are only available as
4-pole with vertical connections.
8.27 [210.0] 8.27 [210.0] 8.27 [210.0]
0.25 [6.4]
0.26 [6.7]
(gap)
(copper bar)
breaker front cover
9.04 [229.5]
5.91 [150.0]
4.33 [110.0]
0.79 [20.0]
0.43 [ 11.0]
M10
35.08 [891]
33.47 [850.0]
8.27 [210.0]
0.16 [4.0] (1)
8.27 [210.0]
breaker front cover
Top view vertical connection Rear view
