19 – 8

19.2 Installing interlocking module

- Switch off and discharge the closing spring

 (page 23-2)

- Remove the breaker from the cradle 

 (page 23-3)

or remove the fixed-mounted breaker if necessary  (page 5-2)

- Remove front panel and side cover on the right, if required

 (page 23-4)

19.2.1 Installing intermediate shaft and coupling

Fitting

WARNING

High speed moving parts.

Can cause serious personal injury.

Discharge the closing spring before inspection and before carrying out any work on the circuit breaker.

Frame size Length L (mm)

I 48

II 118

III 232

Mechanical interlooking module

with ring
