5 – 13
For the screw clamp terminal, a low profile, one-piece, sliding disconnect module is also available.
5.4.3 Secondary disconnect terminal blocks
Versions
(1) Screw clamp terminal system
(2) Ring terminal system
(3) Insulated ring terminal
(4) Screws ANSI B 18.6.3 #4
(5) Spring clamp terminal system
2 terminals per contact
0769
3,0 x 0,6
0,5 Nm
4 lb-in
3,0 x 0,6
(1)
PH 1
(2)
(3)
(4)
1/8“
0,5 Nm
4 lb-in
0,5 Nm
4 lb-in
3,0 x 0,6
1/8“
(5)
