Sonoscape S2 User Manual

S2/S2BW
Digital Color Doppler Ultrasound System
Real time DPI mode menu
Frequency 2.5MHz
Line Density High
Wall Filter 600
B Reject 26
Persis 3
C. Map 4
Power% 60%
When in DPI mode, press
Freeze
to stop the image then press
MENU
, you will see this menu:
Frozen DPI mode menu
C. Map 3
B Reject 26
 Note
• Press the
MENU
key to pop up the adjustment menu;
• Turn the
AUDIO
knob to switch from one item to another;
• Turn the
MENU
key to adjust each parameter.
8.2.1 FREQUENCY
See Section 7.2.1.
8.2.2 Line Density
See Section 7.2.2.
8.2.3 Wall Filter
See Section 7.2.3.
8.2.4 B Reject
See Section 7.2.4.
8.2.5 C Map/DIRECT.D
See Section 7.2.5.
8.2.6 PERSIST
See Section 7.2.6.
8.2.7 POWER
See Section 7.2.7.
P/N: 4710.00149A01
8-2
