S2/S2BW
Digital Color Doppler Ultrasound System
When in PW mode, press
Freeze
to stop the image, then press
Menu
you will see the following
Menu:
Chroma 0
DisplayFormat V1/1
10.2.1 PW FREQUENCY
1.
When in Active PW mode, press
MENU
to display the parameter Menu, then turn
Audio
key to
high-light the “Frequency” item.
2. Turn the
MENU
key to increase or decrease frequency.
10.2.2 Sweep Speed
See Section 9.2.1.
10.2.3 Dynamic Range(DYN)
See Section 6.2.7.
10.2.4 Wall Filter(WF)
See Section 7.2.3.
10.2.5 CHROMA
See Section 9.2.3.
10.2.6 DISPLAY FORMAT
See Section 9.2.2.
10.2.7 POWER
See Section 7.2.7.
10.2.8 Baseline
Adjust the baseline position, you can turn it upper or lower according to the height of the graph you
want to display. You can adjust Baseline position both before and after freezing the image.
Operate:
1. Turn the switch up to move Basline Up
2. Turn the switch down to move Basline Down
P/N: 4710.00149A01
10-3
