Chapter
11
CW
Mode
F
or
basic
CW
operation
guides,
please
ref
er
to
Chapter
10:
PW
Mode.
The
CW
mode
operation
procedures
are
quite
similar
to
the
PW
operation,Except
the
CW
sample
volume
is
not
adjustable
.
(which
means
10.3.4
is
not
applicable
to
CW
mode)
Note
•
CW
mode
is
only
available
on
Phased
Array
transducers,
please
donot
attempt
to
activate
CW
mode
on
other
transducers
(Linear
or
Convex
or
Endocavity
transducers)
11-1
115
117
Table of Contents
Default Chapter
4
Table of Contents
4
1 Introduction
10
2 System Safety and Maintenance
12
Safety Overview
12
Symbol Used
13
Biological Safety
13
Adverse Effects and Precautions
14
Scanning Patients and Education
14
Safe Scanning Guideline
14
Understanding the MI/TI Display
16
Environmental Requirements
18
Electrical Requirements
19
Electrical Safety
20
Transducer Maintenance
21
System Transportation
24
Moving the System
24
Transporting the System
24
3 System Specifications
26
Product Introduction
26
Base System
27
Front View
27
Side View
28
Rear View
29
Keyboard Layout
30
Keyboard Description
30
Probes and Accessories
33
Physical Specifications
33
4 Starting the System
34
Probe Connection
34
Power on and off
34
Using AC Supply
34
Using Battery
36
LED Indicators
37
Patient Information
38
Create New Patient
40
Patient Exam List
49
DICOM Queue
53
PPS Screen
54
Patient Exam Import/Export
54
Select Probes and Exam Mode
57
Main User Interface
58
5 System Setup
60
General Setting
60
General
60
Display
62
Menu
63
Storage
64
Peripheral
65
Comment
66
Bodymark
67
Measure
68
General
68
Menu
69
Formula
70
Report
72
Dicom
73
DICOM Image Storage
73
DICOM Storage Commitment
74
DICOM Worklist
75
Dicom Mpps
76
DICOM Print
77
System Information
79
6 Mode
80
Entering B Mode
80
Parameter Adjustment
80
Focal Number
81
Focal Span
81
Chroma
82
Frequency (Freq)
82
Line Density
82
Sec/Width
83
Dynamic Range (DYN)
83
Gray Scale Curve (GSC)
83
Persist
84
Μ-Scan
84
Compound Imaging
84
Power
85
Gain
85
Focus Position
85
Depth
86
Time Gain Compensation (TGC)
86
Other B Mode Operations
87
Freeze
87
Image Orientation (Left/Right)
87
Image Orientation (Up/Down)
88
Dual- B Dispaly
88
Quad (4B) Display
89
Tissue Harmonic Imaging (THI)
89
7 CFM Mode
92
Enter CFM Mode
92
How to Enter CFM
92
Parameter Adjustment
92
Frequency
93
Line Density
93
Wall Filter (WF)
93
B Reject
94
Color Map (C Map)
94
Persist
94
Power
95
D Gain
95
Prf
95
Steer
95
Other Operations
96
Freeze
96
Single Image
96
Dual Display
96
Quad Display
97
B+CFM Dual Dynamic
98
8 DPI Mode
100
Entering DPI Mode
100
Parameter Adjustment
100
Frequency
101
Line Density
101
Wall Filter
101
B Reject
101
C Map/Direct.D
101
Persist
101
Power
101
D Gain
102
Other Operations
102
9 Mode
104
Starting M Mode
104
Pre-Active Mode
104
Active Mode
104
Parameter Adjustment
105
Sweep Speed
105
Display Format
105
Chroma
106
Smooth(Smo)
106
Other Operations
106
Freeze
106
Adjust M Mode Sampling Line
107
Dual Display
107
10 PW Mode
110
Entering PW Mode
110
Pre-Active Mode
110
Active Mode
110
Parameter Adjustment
111
Pw Frequency
112
Sweep Speed
112
Dynamic Range(DYN)
112
Wall Filter(WF)
112
Chroma
112
Display Format
112
Power
112
Baseline
112
B + PW Other Operations
113
Freeze
113
Adjust PW Sampling Line
113
Adjust PW Sample Volume
114
Adjust PW Sample Angle
114
Adjust Baseline
114
Dual Display
114
11 CW Mode
116
12 Miscellaneous Functions
118
Annotation
118
Textual Annotation
118
Arrow
119
Bodymark
119
Save and Review
121
Customize Exam Mode
123
Create New Exam Mode
124
Exam Mode Management
125
Exam Mode Import and Export
126
Print
127
13 Transducers
128
Transducer Information
128
Supported Transducers
128
Acoustic Output
128
Environmental Requirements
128
Preparation and Usage of the Probe
129
Inspection
129
Probe Connection
129
Preparation for Scanning
129
Scanning
130
Probe Maintenance: Cleaning and Disinfection
130
Probe Immersion Level
130
Cleaning Instructions
131
Disinfection Instructions
131
14 System Maintenance
132
Guidance for Service
132
Manufacturer Responsibility
132
Contact Information
132
