S2/S2BW
Digital Color Doppler Ultrasound System
Operation:
GSC
• Press for B-mode menu, use to select GSC;.
• Twist knob to select differenct GSC .
6.2.9 Persist
Persist is an image processing method, it averages each frame to reduce irrelevant noises. Set a lower Persist
value, you can have better real-timeness of image, but also may cause more noise. A higher Persist value
reduces the noise, improve the smoothnss of image but also reduces real-timeness of the image.
Operation:
Persist
• Press for B-mode menu, use to select Persist;.
•
Twist knob clockwisely to increase the value of Persist, and counterclockwisely to reduce the
value of Persist.
6.2.10 µ-Scan
µ
Scan
ˇ
c
ˇ
nis the function to optimize the ultrasound image. It can reduce speckle noise, enhance contrast
resolution and enhance the display of tissue boundaries.
Operation:
µScan
• Press for B-mode menu, use to select µScan;.
• Twist knob to adjust µScan.
6.2.11 Compound Imaging
In B-mode scanning, sometimes the beam is not vertical to the surface of transducer but has a certain angle.
The final mage is formed by many images of different scanning angles and through image process. The
advantage is to have a better tissue differentiation and enhance the contrast resolution to have a clear edge of
orgain. For a better recognition, the wall of vascular and tissue phrase will be marked specifically.Compound
Imaging can suppress the ultrasound side lobe to enhance the spatial resolution of system and signal-to-noise
ratio to have a better image.
P/N: 4710.00149A01
6-5
