Sony HVO-500MD Instruction Manual

17
Names and Functions of Parts
Chapter 1 Overview
Never remove the USB media when these indicators
are blinking green.
k 1 (on/standby) switch
Use this switch to turn on the unit and the front panel
display.
To completely shut off the power supply, disconnect
the power cord of the AC adapter.
l Disc tray (HVO-550MD only)
Insert discs here.
m Emergency eject hole (HVO-550MD only)
If the disc tray does not open when you press the Z
EJECT button, insert a long, thin object such as a
straightened paper clip into this hole to open the disc
tray.
n Z EJECT button (HVO-550MD only)
Use this to open the disc tray.
o DVD indicator (HVO-550MD only)
Displays the status of the DVD drive.
You cannot remove the disc when this indicator is
blinking green.
Rear
HVO-500MD/550MD
Lit green The recording area of the USB media
is full. Delete any unnecessary
recorded data, or insert different
media.
Lit orange An error has occurred.
Note
Tip
Indicator Status
Indicator Status
Blinking green Data is being written to the DVD disc.
Lit green The recording area of the DVD disc is
full. Insert a different disc.
Lit orange An error has occurred.
Note

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
