Sony HVO-500MD Instruction Manual

40
Image Search
Chapter 4 Recording and Playback
Image Search
You can search for recorded data stored on the unit’s
internal hard disk.
Specifying Search Conditions
Search for recorded data by specifying conditions such as
patient ID and recording date.
1 Press the MENU button.
The [MENU] screen appears.
2 Use the V and v buttons to select [Recording List], and
press the ENTER button.
The [Recording List] screen appears.
3 Use the V, v, B, and b buttons to select [Search], and
press the ENTER button.
The [Search] screen appears.
4 Specify the search conditions.
Select an item using the
V, v, B, and b buttons, and
press the ENTER button to display the text entry
screen for that item.
[Patient ID]
Enter an identification number for the patient using the
on-screen keyboard.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
[Patient Name]
Enter the patient’s name using the on-screen keyboard.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
[Examiner]
Select the name of the examiner performing the exam
in the setting screen that appears, and press the
ENTER button.
[Recording Date]
Select the year, month, and day the images were
recorded in the setting screens that appear, and press
the ENTER button.

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
