Sony HVO-500MD Instruction Manual

28
Handling Discs
Chapter 2 Preparation
Cleaning
• Clean the disc with a soft cloth, wiping it from the center
out. If the dust is heavy, wipe it with a soft cloth
moistened with water, then wipe off the water with a dry
cloth.
• Do not use solvents such as benzene, thinner,
commercially available record cleaners, or anti-static
spray. Using these products may damage discs.
Inserting and Removing Discs
To insert a disc
1 Press the 1 (on/standby) switch to exit standby mode.
“WELCOME” appears on the front panel display.
When the “READY” message appears, proceed to the
following steps.
2 Press the Z EJECT button.
The disc tray opens.
3 Insert the disc.
4 Gently push in the disc tray.
The disc tray closes.
When an incompatible disc is inserted
The DVD indicator lights orange, and a message notifying
you of the incompatible media appears on the menu screen.
Remove the disc, and insert a compatible disc.
To remove a disc
1 Press the Z EJECT button while the unit is turned on.
The disc tray opens.
2 Remove the disc.
3 Gently push in the disc tray to close it.
• The disc tray may take some time to open if
finalization is in progress. Wait a moment for the
finalization process to complete.
• The disc tray cannot be opened while recording is in
progress or paused when simultaneously saving to a
DVD.
1 (on/standby) switch
Z EJECT button
Tips
Data side facing down

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
