Sony HVO-500MD Instruction Manual

70
Network Settings
Chapter 5 System Administrator Settings
[Obtain an IP address automatically]
In the [Obtain an IP address automatically] screen that
appears, select [Use] to use the DHCP to obtain an IP
address automatically, or select [Not Used] to assign a
static IP address manually, and then press the ENTER
button.
If you select [Use], the IP address, subnet mask, and
default gateway will be displayed as read-only.
If you select [Not Used], be sure to configure the [IP
Address], [Subnet Mask], [Default Gateway],
[Preferred DNS Server], and [Alternate DNS Server]
settings.
[IP Address]
Enter the IP address using the on-screen keyboard.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
[Subnet Mask]
Enter the subnet mask using the on-screen keyboard.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
[Default Gateway]
Enter the IP address for the default gateway using the
on-screen keyboard.
If you are only using a local network and not
connecting to other networks, do not configure this
setting.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
[Obtain DNS server address automatically]
In the [Obtain DNS server address automatically]
screen that appears, select [Use] to obtain the IP
address for the DNS server automatically, or select
[Not Used] to specify the IP address manually, and
then press the ENTER button.
If you select [Not Used], be sure to configure the
[Preferred DNS Server] and [Alternate DNS Server]
settings.
[Preferred DNS Server]
Enter the IP address for the preferred DNS server
using the on-screen keyboard.
If you do not have nor need a preferred DNS server, do
not configure this setting.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
[Alternate DNS Server]
Enter the IP address for the alternate DNS server using
the on-screen keyboard.
If you do not have nor need an alternate DNS server,
do not configure this setting.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 26).
5 To configure settings in other tabs, use the V, v, B,
and
b buttons to select a tab.
If you are finished configuring [Network Settings], use
the
V, v, B, and b buttons to select [Apply], and press
the ENTER button to save the configurations.
[File Server] Tab
Configure these settings when specifying a server as the
storage location for recorded data.
1 Use the B and b buttons to select the [File Server] tab.

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
