To use.

■

Click the On/Off button to start the test.

■

Click the Repeat button to run the test continuously.

■

Click the Controls button to open the Mask Test control window.

Behavior. When the Repeat control is on, the test runs continuously. When you click the On/Off button, the test starts using the

parameters from the Mask Test control window and the Pass/Fail Results window is displayed.

What do you want to do next?

Learn about waveform parameters.

Learn about test notification.

Learn about mask polarity.

Learn about the Mask Test Controls window.

Go to the Test Setup control window.

Fail results setup

Mask testing control window (Pass-Fail results tab)

From the Mask menu, select Pass/Fail Results.

Mask testing setups
