To use.
â–
Enter the SMTP server address.
â–
Click OK if you want to accept the default values.
â–
Click More>> if you want to customize your e-mail.
â–
Enter the appropriate information in each box that you need to change from the default.
Behavior. The number you enter in the Number Attempts to Send entry box is the number of times the system will try to send the
e-mail if it is not successful on the first try. The default is 1.
Entering an address in the From entry box puts that address in the From field of the e-mail. The default value is the instrument
model number. Entering your own address allows the instrument to send you e-mail if there is a problem sending to the recipient.
Entering a number in the Timeout entry box will override the default time out for sending e-mail to the server.
If your mail server requires a login or password, enter the login in the Auth Login entry box and the password in the Auth
Password entry box.
Entering a network ID in the Hostname entry box makes the e-mail appear as though it did not come from the instrument.
What do you want to do next?
Learn about E-mail on Event Setup.
Send an e-mail on trigger
To send e-mail on a trigger event, click the E-mail on Trigger button to On.
NOTE. E-mail on Event must be configured to enable E-mail on Trigger (Use the Utilities > E-mail on Event > Setup window).
Fall time
This timing measurement is the time required for the falling edge of the first pulse in the waveform or gated region to fall from the
high reference value (default = 90%) to the low reference value (default = 10%) of the final value.
FastFrame acquisitions
Oscilloscope reference
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 761
