Digital menu
NOTE. The Digital Menu is available only on MSO5000B and MSO70000C/DX Series instruments and DPO5000B Series
instruments with option MSOE installed, and DPO70000DX instruments with option MSOU installed.
Use the Digital menu options to set parameters for the D15-D0 digital channels, and to set up buses based on analog, math, and
digital waveforms from which the instrument can acquire, decode, and display data (or bus forms).
On MSO/DPO5000B Series instruments, you have the option to turn on or turn off the MagniVu feature.
Display menu
Use Display menu options to change the way that waveforms appear on the instrument. This includes the style, intensity, color,
format, text, and persistence. You can also change the graticule type and the items that appear on the display, such as date and
time.
Edit menu
Use the Edit menu for copying images, waveforms, or measurements to the clipboard for use in other applications. You can
select items from the menu or you can select Copy Setup to fine tune the parameters with the Copy control window before
copying items to the clipboard.
You can also use the Edit menu to clear data and undo the last Autoset.
File menu
Use the File menu for basic file operations such as saving, recalling, and deleting waveforms or setups. You can also use the File
menu for standard Windows operations such as printing files and loading the most recent setup.
Horizontal-Acquisition menu
Use the Horizontal/Acquisition menu options to set the horizontal and acquisition parameters for waveforms. This menu also
provides access to the Zoom controls, Autoset, and Fast Acquisitions.
On MSO5000B models and on DPO5000B models with option MSOE, you have the option to turn on or turn off the MagniVu
feature.
Mask menu
Use the Mask menu commands to setup or edit or a user mask.
Math menu
Math menu options enable you to perform mathematical operations on waveforms, build algebraic expressions, perform math-on-
math operations, analyze histograms, or use advanced spectral analysis.
MyScope menu
Use the MyScope Menu to create a new MyScope control window, open or edit an existing one, display the active MyScope
window, or recall recently used ones.
Oscilloscope reference
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 841
