RemotEye 4 User Manual
–
90988-007
211
5000 (3P1) BACnet Analog Point Mapping
Instance ID
Object Name & Description
Units
Comments
Output Parameters
24
Output Voltage
1 Volts
25
Output Rated Voltage
1 Volts
26
Output Voltage Percent
1%
27
Output Rated Voltage
1 Volts
28
Output Current
1 Amp
29
Output Current Percent
%
30
Output Load Percent
%
31
Ouput Rated Current
1 Amp
32
Output Frequency
0.01Hz
33
Output Rated Frequency
0.01Hz
34
Ouput Apparent Power
VA
35
Output Apparent Power Total %
X 1
36
Output Rated Apparent Power
KVA
Bypass Parameters
37
Bypass Voltage
1 Volts
38
Bypass Voltage Percent
%
39
Bypass Rated Voltage
1 Volts
40
Bypass Current
1 Amps
41
Bypass Current %
%
42
Bypass Rated Current
1 Amp
43
Bypass Frequency
0.01Hz
44
Bypass Rated Frequency
0.01 Hz
DC Bus
Parameters
45
DC bus Total Voltage
Vdc
Battery Parameters
46
Batteriy Installed Date
Strings
47
Elapsed Time on Battery Power
Seconds
48
Battery Voltage
Vdc
49
Battery Capacity
%
50
Battery Current
Adc
51
Battery Rated Voltage
1 Volts
210
212
