I.2 BACNET BINARY INPUT POINT MAPPING FOR G9000/G2020 V2
ALL – BACnet Object: Binary Input BACnet Property: Present Value Out of Service: FALSE
Access: Read Only Status Flags: Normal
G9000/G2020 BACnet Binary Input Point Mapping
Instance ID
Object Name & Description
Units
Read From
RMTI
-4
Status
1
RemotEye 4 Data Link
True/False (1/0)
RemotEye
2
RemotEye 4 Network Link
True/False (1/0)
RemotEye
UPS Mode
3
Online Mode
True/False (1/0)
upsOutput (3) (1)
4
Backup Mode
True/False (1/0)
upsOutput (3) (1)
5
Bypass Mode
True/False (1/0)
upsOutput (3) (1)
6
Standby Mode
True/False (1/0)
upsOutput (3) (1)
7
Power Conditioner
True/False (1/0)
upsOutput (3) (1)
Battery Status
8
UPS Battery Status Unknown
True/False (1/0)
upsBattery (6) (1)
9
UPS Battery Status Normal
True/False (1/0)
upsBattery (6) (1)
10
UPS Battery Status Low
True/False (1/0)
upsBattery (6) (1)
11
UPS Battery Status Depleted
True/False (1/0)
upsBattery (6) (1)
12
UPS Battery Status Discharging
True/False (1/0)
upsBattery (6) (1)
EMD
13
EMD Enabled
True/False (1/0)
RemotEye
14
EMD Alarm-1
True/False (1/0)
RemotEye
15
EMD Alarm-2
True/False (1/0)
RemotEye
Faults
16
Alarm Fault
True/False (1/0)
upsAlarmFault
17
DC Bus Overcurrent Fault
True/False (1/0)
upsAlarmDCBusOverCurrent
18
DC Bus Overvoltage Fault
True/False (1/0)
upsAlarmDCBusOverVoltage
19
DC Bus Imbalance Fault
True/False (1/0)
upsAlarmDCBusImbalance
20
DC Undervoltage Fault
True/False (1/0)
upsAlarmDCBusUnderVoltage
21
Output Undervoltage Fault
True/False (1/0)
upsAlarmOutputUnderVoltage
22
Output Overvoltage Fault
True/False (1/0)
upsAlarmOutputOverVoltage
23
UPS Overheat Fault
True/False (1/0)
upsAlarmUPSOverheat
24
Battery Overheat Fault
True/False (1/0)
upsAlarmBatteryOverheat
25
Battery Voltage Abnormal Fault
True/False (1/0)
upsAlarmBatteryVoltageAbnormal
26
UPS Overload Fault
True/False (1/0)
upsAlarmUPSOverload
