Xinje DS5E Series User Manual

129
resistance is too
small
chapter 1.4.1)
Acceleration and
deceleration time is
too short
Extending Acceleration and
Deceleration Time
Hardware damage
The AC gear of the multimeter
measures the input value of the
servo LN (R/S/T), which is 220V ±
10% of the normal value. If the
power supply voltage is more than
220V+10% (380V+10%), check the
power supply voltage; if the power
supply voltage is normal, then in
servo BB state, monitor U0-05, the
voltage measured by the multimeter
* 1.414 < U0-05 (within 10V error),
then the servo driver is faulty and
needs to be sent back for repair.
22
0
E-220
Communication
error of absolute
servo encoder
Absolute value
servo encoder
battery low voltage
alarm (can shield
this alarm)
Absolute value
servo encoder data
access alarm
Motor matching
error
Check if the motor matches
correctly
Unconnected
encoder cable or
poor contact
Disconnect the power supply of the
driver, check the connection of the
encoder cable, if there is cable
loosening, it is recommended to use
the multimeter to test the
conduction condition; after
eliminating errors, power on again
Hot plugging is strictly prohibited,
and special cables are required for
tank chains.
Received encoder
data errors, and the
number of errors
exceeds the number
of error retries of
encoder registers
P0-56
Encoder wire and strong power do
not have the same pipeline wiring;
install filter on servo driver power
input side; encoder wire sleeves
magnetic ring; shut down welding
machine type of equipment with
large interference
2
E-222
Absolute Servo
Encoder Value
Overflow
Communication
error of absolute
servo encoder
Battery Voltage in
Battery Box of
Encoder cable is
less than 2.75V
Please replace the battery while
keeping the power supply ON of the
servo driver in order to avoid the
error of encoder position
information. Battery specification:
No.5 battery, 3.6V (model
CP-B-BATT, CPT-B-BATT)
Power on alarm for
new machine
(1) When the absolute value motor
is powered off, the memory position
depends on the battery on the
encoder cable. Once the encoder
cable and the motor are
disconnected, the power supply can
not be carried out, which will lead
to the loss of the current position of
the motor, it will alarm 222.
Please set F0-00=1 to clear the
alarm, it can be used normally.
(2) The alarm can be shielded by
using F0-79. When P0-79 is set to
1, it will be used as a single-loop
absolute value motor, and the
current position will not be
