66
(2) Input signal setting
Defaulted is not distribute to input
terminal
/Z-CLAMP signal is
distributed to input
terminal by parameter
P5-31, Range:
0000-0014.
Input signal from SI2 terminal
(3) Parameter setting
ZCLAMP input signal is ON, forced speed command is 0, when the speed below
P3-13, switch to position mode and the servo lock in this position.
ZCLAMP input signal is ON, forced set the speed command to 0.
ZCLAMP input signal is ON, the speed below P3-13, switch to position mode and
the servo lock in the position.
Note: after entering zero clamp mode, present setting speed is higher than P3-13,
motor doesn’t run, the ZCLAMP signal must be OFF, then motor will run again.
ZCLAMP signal is ON, the setting speed is less than P3-13, switch to position
control mode, and servo is locked at this position. At this time, if setting speed is
over P3-13, the motor will run again.
5.6.7 Torque limit
1. Internal torque limit
Internal Forward
torque limit
Internal reverse
torque limit
1. if this parameter value is less than external torque limit value, the final limit value is this parameter.
2. The unit is percent of the motor rated torque; the default value is 300%. The real max output torque
is limited by motor overload times.
2. External torque limit (via input signal)
Forward external
torque limit
Reverse external
torque limit
The unit is the percent of motor rated torque; the default value is 300%.
