Basic Programming 5 - 11
Preset Reference
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
Setting Range: 0.0 to E1-04 (Maximum Output Frequency)
Factory Default: 0.0Hz
d1-17 Jog Reference
Setting Range: 0.0 to E1-04 (Maximum Output Frequency)
Factory Default: 6.0Hz
Up to 17 preset references (including Jog Reference) can be set through multi-function inputs S3 to S8. The first 4 preset
references and Jog Reference are accessible through the Quick Setting menu. It is a two-step process to set the Drive up for
preset speeds. First, d1-01 through d1-04 and d1-17 must be programmed with the desired preset speeds and the desired jog
speed, respectively. Next, three of the Drive’s digital inputs need to be programmed and wired as Multi-step Speed Reference
1, Multi-step Speed Reference 2, and Jog Frequency.
As shown in the above table, it is possible to use analog inputs in place of Frequency Reference 1 and Frequency Reference 2.
If b1-01 = 1, then the analog input A1 will be used instead of Frequency Reference 1 for the first preset speed. If b1-01=0
then Frequency Reference 1 (d1-01) will be used.
If H3-05 = 2, then the analog input A2 will be used instead of Frequency Reference 2 (d1-02) for the second preset speed.
If H3-05 ≠ 2, then Frequency Reference 2 will be used.
Table 5.2 Preset Speed
Preset Speed
Terminal
programmed
as Multi-step
Reference 1
Terminal
programmed
as Multi-step
Reference 2
Terminal
programmed
as Jog
Reference
Details
1 OFF OFF OFF Frequency Reference 1 (d1-01) or analog input A1
2 ON OFF OFF Frequency Reference 2 (d1-02) or analog input A3
3 OFF ON OFF Frequency Reference 3 (d1-03)
4 ON ON OFF Frequency Reference 4 (d1-04)
5 - - ON* Jog Frequency (d1-17)
* The Jog Frequency input is given priority over the multi-step speeds.
IMPORTANT
The programming of d1-01 through d1-17 will be in the units specified by the display scaling parameter (o1-03).
