Specifications C - 2

Standard Drive Specifications

The standard Drive specifications are listed in the following tables.

 208-240Vac

Table C.1 208-240Vac Drive Specifications

208-240Vac Drives

208-230Vac Drives

Model Number CIMR-

F7U

20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090

2110

Rated output

capacity

(kVA)

1.2 1.6 2.7 3.7 5.7 8.8 12.0 17.0 22.0 27.0 32.0 44.0 55.0 69.0 82.0 110.0 130.0 140.0

Horsepower

0.5/0.75 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125 150

Rated output

current

(A)

3.2 4.2 7.0 9.6 15.2 23.0 31.0 45.0 58.0 71 85.0 115.0 145.0 180.0 215 283.0 346.0 360.0

Overload capacity

(% of rated output

current for 60 sec)

150

138

Current limit (% of

rated output current)

150

138

Carrier frequency

*5,*7

2kHz

Maximum output

frequency

300.0Hz

Rated output

capacity

(kVA)

1.4 1.8 3.0 4.1 6.4 8.8 12.0 18.0 23.0 29.0 34.0 44.0 62.0 73.0 82.0 120.0 140.0 160.0

Horsepower

0.5/0.75 1 2 3 5 7.5 10 15 20 25 30 40 50/60 75 - 100/125 150 -

Rated output

current

(A)

3.6 4.6 7.8 10.8 16.8 23.0 31.0 46.2 59.4 74.8 88.0 115.0 162.0 192.0 215 312.0 360.0 415.0

Overload capacity

(% of rated output

current for 60 sec.)

107 107 108 107 107 120 120 117 117 114 116 120 107 113 120 109 115 120

Current limit (% of

rated output current)

120

Carrier frequency

(kHz)

10 10 10 8 10 15 15 8 10 10 10 10 5 5 8 2 2 2

Maximum output

frequency

400.0Hz

Maximum output

voltage

3-phase; 200, 208, 220, 230, or 240Vac

(Proportional to input voltage)

Rated voltage

Rated frequency

3-phase, 200/208/220/230/240Vac, 50/60Hz 3-phase, 200/208/220/230Vac, 50/60Hz

Rated input current -

Heavy Duty

(A)

3.8 4.9 8.4 11.5 18 24 37 52 68 84 94 120 160 198 237 317 381 396

Rated input current -

Normal Duty

(A)

4.3 5.5 9.4 13 20 24 37 53 70 89 98 120 180 212 237 350 396 457

Allowable voltage

fluctuation

+ 10%, - 15%

Allowable frequency

fluctuation

±5%

Measures

for power

supply

harmonics

Reactor

Optional Built-in

12-Pulse

Rectification

Not possible

Possible

*1 The difference between Heavy Duty ratings and the Normal Duty ratings for the Drive are the rated input and output current, overload capacity, carrier frequency, current limit, and maxi-

mum output frequency. Parameter C6-01 must be set to value of “0” for Heavy Duty ratings and “2” for Normal Duty ratings. Factory default is Heavy Duty (C6-01=0).

*2 Horsepower ratings are based on 230V or 460V NEC Table 430.150. The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor and Drive,

be sure that the Drive's rated output current is appropriate for the motor's rated current.

*3 Model 2110 has an overload rating of 138% of rated output current for 60 seconds and a current limit rating of 138%. Models 4220 and 4300 have an overload rating of 150% of rated output

current for 45 seconds and a current limit rating of 150%.

*4 When setting the carrier frequency above the factory default, the Drive must be derated.

*5 Heavy Duty ratings for models 2110, 4220 and 4300 are effective in software version VSF103021 and higher.

*6 Each value shown is the Maximum carrier frequency and default carrier frequency.

*7 The carrier frequency for Heavy Duty is default to 2 kHz. Software version VSF103021 and higher may allow the carrier frequency to be increased above 2 kHz with a reduction in

continuous rated output current. Refer to C6-02 in Chapter 5 for further details.

utput rat

ngs

Heavy Duty

Normal Duty
