Capacity Related Parameters B - 3
Parameters Affected by Drive Capacity Setting
The factory setting of the parameters in Table B.2 may change when the Drive capacity is changed via parameter o2-04. See
Table B.3 and B.4 for a complete list.
Table B.2 Parameters Affected by o2-04
Parameter
Number
Parameter Name
Digital Operator Display
Parameter
Number
Parameter Name
Digital Operator Display
b8-03
Energy Saving Control Filter Time Constant
Energy Saving F.T
E4-02
Motor 2 Rated Slip
Motor Rated Slip
b8-04
Energy Saving Coefficient Value
Energy Save COEF
E4-03
Motor 2 No-Load Current
No-Load Current
C6-01
Carrier Frequency Duty
Heavy/Normal Duty
E4-05
Motor 2 Line-to-Line Resistance
Term Resistance
E2-01
Motor Rated Current
Motor Rated FLA
E4-06
Motor 2 Leakage Inductance
Leakage Inductance
E2-02
Motor Rated Slip
Motor Rated Slip
E4-07
Motor 2 Rated Output
Motor 2 Rated KW
E2-03
Motor No-load Current
No-load Current
L2-02
Momentary Power Loss Ride-thru Time
PwrL Ridethru t
E2-05
Motor Line-to-Line Resistance
Term Resistance
L2-03
Momentary Power Loss Minimum Base Block Time
PwrL Baseblock t
E2-06
Motor Leakage Inductance
Leakage Inductance
L2-04
Momentary Power Loss Voltage Recovery Ramp Time
PwrL V/F Ramp t
E2-10
Motor Iron Loss for Torque Compensation
Tcomp Iron Loss
L8-02
Overheat Pre-Alarm Level
OH Pre-Alarm Lvl
E2-11
Motor Rated Output
Motor Rated KW
o2-04
Drive/kVA Selection
Inverter Model #
E4-01
Motor 2 Rated Current
Motor Rated FLA
--
