YASKAWA F7 User Manual

Spare Parts F - 2
F7 Primary Spare Parts - 208/230/240Vac
Table F.1 208-240Vac F7 Primary Spare Parts
Drive Model
CIMR-F7U
Hp
Power PCB
(3PCB)
Gate Drive PCB
(3PCB)
Control PCB
(1PCB)
Terminal PCB
(2PCB)
Diode Module
20P4
0.5/0.75
ETP617012 N/A ETC618390-S3020 ETC618410 Inside the Power Module
20P7
1
ETP617012 N/A ETC618390-S3020 ETC618410 Inside the Power Module
21P5
1.5/2
ETP617022 N/A ETC618390-S3020 ETC618410 Inside the Power Module
22P2
3
ETP617032 N/A ETC618390-S3020 ETC618410 Inside the Power Module
23P7
5
ETP617042 N/A ETC618390-S3020 ETC618410 Inside the Power Module
25P5
7.5
ETP617052 N/A ETC618390-S3020 ETC618410 Inside the Power Module
27P5
10
ETP617062 N/A ETC618390-S3020 ETC618410 Inside the Power Module
2011
15
ETP617422 N/A ETC618390-S3020 ETC618410 SID003114 (D1)
2015
20
N/A ETC617032 ETC618390-S3020 ETC618410 SID003113 (D1)
2018
25
N/A ETC617042 ETC618390-S3020 ETC618410 SID003113 (D1)
2022
30
N/A ETC617053 ETC618390-S3020 ETC618410 SID003114 (D1,D2)
2030
40
N/A ETC617063 ETC618390-S3020 ETC618410 SID003113 (D1,D2)
2037
50
N/A ETC617073 ETC618390-S3020 ETC618410 SID003130 (D1,D2)
2045
60
N/A ETC617083 ETC618390-S3020 ETC618410 SID003115 (D1,D2)
2055
75
N/A ETC617093 ETC618390-S3020 ETC618410 SID003115 (D1,D2)
2075
75/100
N/A ETC617103 ETC618390-S3020 ETC618410 SID003116 (D1-D6)
2090
125
N/A ETC617113 ETC618390-S3020 ETC618410 SID003116 (D1-D6)
2110
150
N/A ETC617531 ETC618390-S3020 ETC618410 SID003108 (D1-D12)
Table F.1 208-240Vac F7 Primary Spare Parts (Continued)
Drive Model
CIMR-F7U
Hp Power Module Transistor Module DC Bus Fuse Heat Sink Fan Internal Fan
20P4
0.5/0.75
STR001297 (Q1) N/A FU-002029 (F1) N/A N/A
20P7
1
STR001297 (Q1) N/A FU-002029 (F1) N/A N/A
21P5
1.5/2
STR001299 (Q1) N/A FU-002029 (F1) N/A N/A
22P2
3
STR001301 (Q1) N/A FU-002030 (F1) N/A N/A
23P7
5
STR001303 (Q1) N/A FU-002031 (F1) FAN001066 (B1) N/A
25P5
7.5
STR001304 (Q1) N/A FU-002099 (F1) FAN001066 (B1) N/A
27P5
10
STR001278 (Q1) N/A FU-002107 (F1) FAN001066 (B1,B2) N/A
2011
15
N/A STR001315 (Q1) FU-002108 (F1) FAN001066 (B1,B2) FAN001043 (B3)
2015
20
N/A STR001315 (Q1) FU-002108 (F1) FAN001065 (B1,B2) N/A
2018
25
N/A STR001320 (Q1) FU-002109 (F1) FAN001065 (B1,B2) FAN001043 (B3)
2022
30
N/A STR001314 (Q1) FU-002110 (F1) FAN001039 (B1,B2) N/A
2030
40
N/A STR001323 (Q1) FU-002110 (F1) FAN001039 (B1,B2) N/A
2037
50
N/A STR001293 (Q1-Q3) FU-002102 (F1) FAN001049 (B1,B2) FAN001053 (B4)
2045
60
N/A STR001335 (Q1-Q3) FU-000925 (F1) FAN001049 (B1,B2) FAN001053 (B4)
2055
75
N/A STR001335 (Q1-Q3) FU-000938 (F1) FAN001052 (B1,B2) FAN001054 (B4)
2075
75/100
N/A STR001349 (Q1-Q6) FU-000926 (F1) FAN001056 (B1,B2) FAN001054 (B4)
2090
125
N/A STR001338 (Q1-Q6) FU-002105 (F1) FAN001056 (B1,B2) FAN001054 (B4)
2110
150
N/A STR001351 (Q1-Q12) FU-002106 (F1) FAN001056 (B1,B2) FAN001054 (B4)
