 480Vac

Table i.3 480Vac Drive Specifications

Model Number CIMR-F7U 40P4 40P7 41P5 42P2 43P7 44P0 45P5 47P5 4011 4015 4018 4022

Rated output

capacity

(kVA)

1.4 1.6 2.8 4.0 5.8 6.6 9.5 13.0 18.0 24.0 30.0 34.0

Horsepower

0.5/0.75 1 1.5/2 3 5 - 7.5 10 15 20 25 30

Rated output current (A) 1.8 2.1 3.7 5.3 7.6 8.7 12.5 17.0 24.0 31.0 39.0 45.0

Overload capacity

(% of rated output

current for 60 sec.)

150

Current limit (% of rated

output current)

150

Carrier frequency

2kHz

Maximum output

frequency

300.0Hz

Rated output capacity

(kVA)

1.4 1.6 2.8 4.0 5.8 6.6 9.5 13.0 21.0 26.0 30.0 38.0

Horsepower

0.5/0.75 1 1.5/2 3 5 - 7.5 10 15/20 25 30 30

Rated output current

(A)

1.8 2.1 3.7 5.3 7.6 8.7 12.5 17.0 27.0 34.0 40.0 50.4

Overload capacity

(% of rated output

current for 60 sec.)

120 120 120 120 120 120 120 120 107 109 117 107

Current limit (% of rated

output current)

120

Carrier frequency (kHz)

15 15 15 15 15 15 15 15 8 10 10 10

Maximum output

frequency

400.0Hz

Maximum output voltage 3-phase; 380, 400, 415, 440, 460, or 480Vac (Proportional to input voltage)

Model Number CIMR-F7U 4030 4037 4045 4055

4075 4090 4110

4132 4160 4185 4220 4300

Rated output capacity

(kVA)

46.0 57.0 69.0 85.0 110.0 140.0 160.0 200.0 230.0 280.0 315.0 450.0

Horsepower

40 50 60 75 100 125/150 - 200 250 300 350 500

Rated output current

(A)

60.0 75.0 91.0 112.0 150.0 180.0 216.0 260.0 304.0 370.0 414.0 590.0

Overload capacity

(% of rated output

current for 60 sec.)

150

Current limit (% of rated

output current)

150

Carrier frequency

2kHz

Maximum output

frequency

300.0Hz

Rated output capacity

(kVA)

51.0 59.0 73.0 95.0 120.0 140.0 180.0 200.0 230.0 315.0 390.0 510.0

Horsepower

40/50 60 75 100 125 150 200 - 250 300/350 400/450 500+

Rated output current

(A)

67.2 77.0 96.0 125.0 156.0 180.0 240.0 260.0 304.0 414.0 515.0 675.0

Overload capacity

(% of rated output

current for 60 sec.)

107 117 114 108 115 120 108 120 120 107 118 120

Current limit (% of rated

output current)

120

Carrier frequency (kHz)

88855855522 2

Maximum output

frequency

400.0Hz

Maximum output voltage 3-phase, 380, 400, 415, 440, 460 or 480Vac (Proportional to input voltage)

*1 The difference between Heavy Duty ratings and the Normal Duty ratings for the Drive are the rated input and output current, overload capacity, carrier frequency, current limit, and

maximum output frequency. Parameter C6-01 must be set to value of “0” for Heavy Duty ratings and “2” for Normal Duty ratings. Factory default is Heavy Duty (C6-01=0).

*2 Horsepower ratings are based on 230V or 460V NEC Table 430.150. The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor

and Drive, be sure that the Drive's rated output current is appropriate for the motor's rated current.

*3 Model 2110 has an overload rating of 138% of rated output current for 60 seconds and a current limit rating of 138%. Models 4220 and 4300 have an overload rating of 150% of

rated output current for 45 seconds and a current limit rating of 150%.

*4 When setting the carrier frequency above the factory default, the Drive must be derated.

*5 Heavy Duty ratings for models 2110, 4220 and 4300 are effective in software version VSF103021 and higher.

utput rat

ngs

Heavy Duty

Normal Duty

utput rat

ngs

Heavy Duty

Normal Duty
