YASKAWA F7 User Manual

Physical Installation 1 - 2
F7 Model Number, Enclosure, Heat Loss, and Weight
Table 1.1 F7 Model Number and Enclosure Style
Input
Voltage
3-Phase
F7
Model-Number
Enclosure Style
Weight
lb (kg)
Heat Loss (watts)
Heatsink Internal Total
208-240Vac
CIMR-F7U20P4 NEMA Type 1 (IP20)
6.6 (3.0)
19 39 58
CIMR-F7U20P7 NEMA Type 1 (IP20) 26 42 68
CIMR-F7U21P5 NEMA Type 1 (IP20) 48 50 98
CIMR-F7U22P2 NEMA Type 1 (IP20) 68 59 127
CIMR-F7U23P7 NEMA Type 1 (IP20)
8.8 (4.0)
110 74 184
CIMR-F7U25P5 NEMA Type 1 (IP20) 164 84 248
CIMR-F7U27P5 NEMA Type 1 (IP20) 13.2 (6.0) 219 113 332
CIMR-F7U2011 NEMA Type 1 (IP20) 15.4 (7.0) 357 168 525
CIMR-F7U2015 NEMA Type 1 (IP20)
24.2 (11.0)
416 182 598
CIMR-F7U2018 NEMA Type 1 (IP20) 472 208 680
CIMR-F7U2022 NEMA Type 1 (IP20) 53 (24) 583 252 835
CIMR-F7U2030 NEMA Type 1 (IP20) 59 (27) 883 333 1216
208-230Vac
CIMR-F7U2037 Open Chassis (IP00) 125 (57) 1010 421 1431
CIMR-F7U2045 Open Chassis (IP00) 139 (63) 1228 499 1727
CIMR-F7U2055 Open Chassis (IP00) 189 (86) 1588 619 2207
CIMR-F7U2075 Open Chassis (IP00) 191 (87) 1956 844 2800
CIMR-F7U2090 Open Chassis (IP00) 238 (108) 2194 964 3158
CIMR-F7U2110 Open Chassis (IP00) 330 (150) 2733 1234 3967
480 Vac
CIMR-F7U40P4 NEMA Type 1 (IP20)
6.6 (3.0)
14 39 53
CIMR-F7U40P7 NEMA Type 1 (IP20) 17 41 58
CIMR-F7U41P5 NEMA Type 1 (IP20) 36 48 84
CIMR-F7U42P2 NEMA Type 1 (IP20)
8.8 (4.0)
59 56 115
CIMR-F7U43P7 NEMA Type 1 (IP20) 80 68 148
CIMR-F7U44P0 NEMA Type 1 (IP20) 90 70 160
CIMR-F7U45P5 NEMA Type 1 (IP20) 127 81 208
CIMR-F7U47P5 NEMA Type 1 (IP20)
13.2 (6.0)
193 114 307
CIMR-F7U4011 NEMA Type 1 (IP20) 232 158 390
CIMR-F7U4015 NEMA Type 1 (IP20)
22 (10)
296 169 465
CIMR-F7U4018 NEMA Type 1 (IP20) 389 201 590
CIMR-F7U4022 NEMA Type 1 (IP20)
53 (24)
420 233 653
CIMR-F7U4030 NEMA Type 1 (IP20) 691 298 989
CIMR-F7U4037 NEMA Type 1 (IP20)
88 (40)
801 332 1133
CIMR-F7U4045 NEMA Type 1 (IP20) 901 386 1287
CIMR-F7U4055 NEMA Type 1 (IP20) 1204 478 1682
CIMR-F7U4075 Open Chassis (IP00) 194 (88) 1285 562 1847
CIMR-F7U4090 Open Chassis (IP00) 196 (89) 1614 673 2287
CIMR-F7U4110 Open Chassis (IP00) 224 (102) 1889 847 2736
CIMR-F7U4132 Open Chassis (IP00) 265 (120) 2388 1005 3393
CIMR-F7U4160 Open Chassis (IP00) 352 (160) 2791 1144 3935
CIMR-F7U4185 Open Chassis (IP00) 572 (259) 2636 1328 3964
CIMR-F7U4220 Open Chassis (IP00) 616 (279) 3797 1712 5509
CIMR-F7U4300 Open Chassis (IP00) 891 (404) 5838 2482 8320
