Digital Operator 3 - 11
Quick Setting Menu (-QUICK-)
This menu is used to set/read the most commonly used parameters in the Drive. Follow the key operations in Fig 3.6 to access
the Quick Setting Menu:
Fig 3.6 Quick Setting Parameter Access Procedure
Use and keys to scroll through the “Quick Setting” parameter list.
Table 3.11 Quick Setting Parameter List
Parameter
Number
Parameter Name
A1-02 Control Method Selection
b1-01 Frequency Reference Selection
b1-02 Run Command Selection
b1-03 Stopping Method Selection
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
C6-02 Carrier Frequency Selection
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
d1-17 Jog Reference
E1-01 Input Voltage Setting
E1-03 V/F Pattern Selection
E1-04 Maximum Output Frequency
E1-05 Maximum Output Voltage
E1-06 Base Frequency
E1-09 Minimum Output Frequency
E1-13 Base Voltage
E2-01 Motor Rated Current
E2-04 Number of Motor Poles
E2-11 Motor Rated Output
F1-01 PG Pulses / Revolution
F1-21
<3021> PG Pulse / Revolution 2
F1-22
<3021> PG Rotation Selection
H4-02 Terminal FM Gain Setting
H4-05 Terminal AM Gain Setting
L1-01 Motor Overload Protection Selection
L3-04 Stall Prevention Selection During Decel
Note: Refer to Appendix A for control method dependent parameters.
