Electrical Installation 2 - 38
PG-W2
The terminal specifications for the PG-W2 are given in Table 2.22.
Table 2.22 PG-W2 Terminal Specifications
Terminal No. Contents Specifications
J2
1
Power supply for Pulse Generator
12Vdc (±5%), 200mA max.
2 0Vdc (GND for power supply)
3
A1-phase input terminals
Pulse generator 1 input
Line driver input
(RS-422 level input)
4
5
B1-phase input terminals
6
7
Z1-phase input terminals
8
9Shield -
10
A2-phase input terminals
Pulse generator 2 input
Line driver input
(RS-422 level input)
11
12
B2-phase input terminals
J1
13
14
Z2-phase input terminals
15
16 Shield connection terminal -
17
A-phase output terminals
Pulse monitor output.
Source depends on software parameter
Line driver output
(RS-422 level output)
18
19
B-phase output terminals
20
21
Z-phase output terminals
22
23 Shield connection terminal -
24 0Vdc For pulse monitor terminals 17-22
