Parameters A - 3
F7 Parameter List
Table A.1 F7 Parameter List
Parameter
No.
Parameter Name
Digital Operator Display
Description
Setting
Range
Factory
Setting
Control Method
V/F
V/F
w/PG
Open
Loop
Vector
Flux
Vector
Initialization
A1-00
Language Selection
Select Language
Language selection for the Digital Operator.
This parameter is not reset to the factory setting by A1-03.
0: English
1: Japanese
2: Deutsch
3: Francais
4: Italiano
5: Espanol
6: Portugues
0 to 6 0 A A A A
A1-01
Access Level Selection
Access Level
Selects which parameters are accessible via the Digital Operator.
0: Operation Only
1: User Level (only available if A2 parameters have been set)
2: Advanced Level
0 to 2 2 A A A A
A1-02
Control Method Selection
Control Method
Selects the Control Method of the Drive.
0: V/F control without PG
1: V/F control with PG
2: Open Loop Vector
3: Flux Vector (Closed Loop Vector)
0 to 3 2 Q Q Q Q
A1-03
Initialize Parameters
Init Parameters
Used to return all parameters to their factory or user default
settings. (Initializes and then returns A1-03 to zero.)
0: No Initialize
1110: User Initialize (The user must first set their own parameter
values and then store them using parameter o2-03.)
2220: 2-Wire Initialization
3330: 3-Wire Initialization
0 to
3330
0AAA A
A1-04
Password 1
Enter Password
When the value set into A1-04 does NOT match the value set into
A1-05, parameters A1-01 thru A1-03 and A2-01 thru A2-32 cannot
be changed. All other parameters as determined by A1-01 can be
changed. Parameter A1-05 can be accessed by pressing the MENU
key while holding the RESET key.
0 to 9999 0 A A A A
A1-05
Password 2
Select Password
0 to 9999 0 A A A A
User Parameters
A2-01
User Parameter 1
User Param 1
Selects the parameters to be available in the User Access Level
(A1-01 = 1). These parameters are not related to the User Initialize
function.
b1-01
to
o3-02
–
AA A A
A2-02
User Parameter 2
User Param 2
–
AA A A
A2-03
User Parameter 3
User Param 3
–
AA A A
A2-04
User Parameter 4
User Param 4
–
AA A A
A2-05
User Parameter 5
User Param 5
–
AA A A
A2-06
User Parameter 6
User Param 6
–
AA A A
A2-07
User Parameter 7
User Param 7
–
AA A A
A2-08
User Parameter 8
User Param 8
–
AA A A
A2-09
User Parameter 9
User Param 9
–
AA A A
Denotes that parameter can be changed when the Drive is running.
