YASKAWA F7 User Manual

Basic Programming 5 - 18
Table 5.5 V/F Pattern for Drive Capacity F7U2055 and higher for 200V Class
Parameter
No.
Name Unit Factory Setting
E1-03
V/F Pattern Selec-
tion
–0 1 2 3 4 5 6 7
E1-04
Max. Output
Frequency
Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0
E1-05 Max. Output Voltage V 230.0 230.0 230.0 230.0 230.0 230.0 230.0 230.0
E1-06
Max. Voltage
Frequency
Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0
E1-07
Mid. Output
Frequency
V 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0
E1-08 Mid. Output Voltage V 13.8 13.8 13.8 13.8 40.2 57.5 40.2 57.5
E1-09
Min. Output
Frequency
Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5
E1-10 Min. Output Voltage V 6.9 6.9 6.9 6.9 5.7 6.9 5.7 6.9
1. For 400V class units, the voltage values are twice that of 200V class units.
2. These default values are for V/F or V/F with PG control methods (A1-02 = 0 or 1)
Table 5.5 V/F Pattern for Drive Capacity F7U2055 and higher for 200V Class (continued)
Parameter
No.
Name Unit Factory Setting
E1-03
V/F Pattern Selec-
tion
–8 9 AB C D EF & FF
E1-04
Max. Output
Frequency
Hz 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0
E1-05 Max. Output Voltage V 230.0 230.0 230.0 230.0 230.0 230.0 230.0 230.0
E1-06 Base Frequency Hz 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07
Mid. Output
Frequency
V 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0
E1-08 Mid. Output Voltage V 17.2 23.0 17.2 23.0 13.8 13.8 13.8 13.8
E1-09
Min. Output
Frequency
Hz 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5
E1-10 Min. Output Voltage V 8.0 10.3 8.0 12.6 6.9 6.9 6.9 6.9
1. For 400V class units, the voltage values are twice that of 200V class units.
2. These default values are for V/F or V/F with PG control methods (A1-02 = 0 or 1)
