114
HITCHES
E466 E467
WORKING AND TRANSPORT POSI-
TION OF THE FRONT THREE-POINT
HITCH
A
working position of the front
three-point hitch
B
transport position of the front
three-point hitch
Change of position of the front three-
point hitch tie-rods:
1. unlock and remove the pin (1) from
the hole
2. lift the arm from position (A) to posi-
tion (B)
3. install the pin into hole (2) and lock
the pin to lock the arm
Fit only the pin into holes and
never check the pass-through
ability by your fingers!
TRACTOR OPERATION WITH IMPLE-
MENTS ATTACHED TO THE FRONT
THREE-POINT HITCH
The maximum permissible speed
when driving the tractor with
agricultural machines attached to
the front three-point hitch is
15 km/h.
If no implement or ballast is at-
tached to the front three-point
hitch, we recommend lifting the
lower lifting tie-rods into the
transport position.
