47
ACQUAINTANCE WITH TRACTOR
E158 E159 E160
TRACTORS WITH TRAVELLING
SPEED OF 40 KM.H
-1
All tractor models with front driving axle,
which have brakes installed in front
wheels gear reductions, may reach the
travelling speed of 40 km.h
-1
.
FUEL TANK
The fuel tank is fitted on the right-hand
tractor side. The plastic fuel tank with
capacity of 120 litres is assembled as
standard for all tractor types.
Do not step on the fuel tank!
FUEL TANK DRAIN PLUG
The hole to drain impurities is located at
the bottom of fuel tank.
AVERAGE FUEL CONSUMPTION IN
LITRES PER OPERATING HOUR FOR
ZETOR TRACTORS
Tractor type Engine load
100% 80% 50%
Z 8541 18.42 14.44 9.21
Z 9541 20.34 16.27 10.17
Z 10541 22.63 18.11 11.32
