TRACTOR MAINTENANCE
TRACTOR LUBRICATION CHART
Item Lubrication point - inspection Sorts of fillings
1 Cooling system – coolant change See Tab. 8
2 Engine - oil change See Tab. 1
3 Steering oil tank See Tab. 4
4 Brake fluid tank See Tab. 6
5 Gearbox See Tab. 2
6 Driver’s seat (handle and seat rollers) See Tab. 5
7 Driver’s seat shock absorber Shock-absorber oil
8 Front axle bracket pivot pin (2 nipples) See Tab. 5
12 Connecting rod of force control (1 nipple) See Tab. 5
13 Pins of auxiliary hydraulic cylinder (2 or 4 nipples) See Tab. 5
15 Lifting tie-rods of three point hitch (2 nipples) See Tab. 5
16 Torsion bar of force control (1 nipple) See Tab. 5
17 Bowden cable control for one-axle trailer hitch, hand parking
brake
See Tab. 5
18 Hating fan bearings See Tab. 1
19 Bearings and lever mechanism of wipers See Tab. 5
20 Left lifting arm pin See Tab. 5
21 Lower pin of three-point hitch support See Tab. 5
22 Clutch release shaft (2 nipples) See Tab. 5
23 Cab door hinges See Tab. 1
24 Tensioning nuts of lower tie-rods See Tab. 5
28 Gearbox of front PTO shaft See Tab. 2
29 Pins of front three-point hitch See Tab. 5
