Zte ZXR10 2928 User Manual

ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
144 Confidential and Proprietary Information of ZTE CORPORATION
TABLE 234 SHOW QOS POLICY COUNTER COMMAND
Format Mode Function
show qos counter
[<0-31>]
global config This views qos
policy counter
Result: This views qos policy counter.
6. To view policy for traffic, use command show policy
[mirror | redirect | qos-remark | vlan-remark |statistic
| policing [<0-255>]] in global configuration mode. This
is shown in
Table 235.
TABLE 235 SHOW POLICY COMMAND
Format Mode Function
show policy
[mirror | redirect
| qos-remark |
vlan-remark
|statistic |
policing [<0-
255>]]
global config This views policy for
traffic
Result: This views policy for traffic.
E
ND OF STEPS
QoS including data packet priority has been configured.
This example shows overall situation of QoS profile. Value is
{TC=5，DP=1，UP=5，DSCP=33}.
zte(cfg)#set qos profile 66 tc 5 dp 1 up 5 dsc 33
zte(cfg)#show qos profile 66
ProfileIndex tc dp up dscp
------------- ---- ---- ---- -----
66 5 1 5 33
To set upÆprofile mapping is 5Æ55, set dscpÆprofile mapping
is 33Æ66.
zte(cfg)#set qos up-to-profile 5 55
zte(cfg)#set qos dscp-to-profile 33 66
zte(cfg)#show qos up-to-profile 5
up ProfileIndex
---- -------------
5 55
zte(cfg)#show qos dscp-to-profile 33
dscp ProfileIndex
---- -------------
33 66
Result
Example

Zte ZXR10 2928 Specifications

General

MAC Address Table Size	16K
VLAN	4K
Jumbo Frame	9K
Power Supply	AC 100-240V, 50/60Hz
Power Consumption	< 30W
Dimensions	440mm x 200mm x 44mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports
