Chapter 9 Network Management
Confidential and Proprietary Information of ZTE CORPORATION 249
Configuring Cluster
This topic describes the cluster configuration. Unique ID of a
cluster consists of VLAN where cluster is located and MAC
address of command switch.
For the configuration of cluster, perform the following steps.
1. To set candidate switches, use command set group
candidate in group config mode. This is shown in
Table
407.
TABLE 407 SET GROUP CANDIDATE COMMAND
Format Mode Function
set group
candidate
group config This sets candidate
switches
Result: This sets candidate switches.
2. To set independent switches, use command set group
independent in group config mode. This is shown in
Table
408.
TABLE 408 SET GROUP INDEPENDENT COMMAND
Format Mode Function
set group
independent
group config This sets
independent
switches
Result: This sets independent switches
3. To set a command switch, specify a layer 3 port number
for cluster management and set IP address pool for user
cluster management, use command set group
commander ipport <0-63> ip-pool < A. B. C. D/M >
in group config mode. This is shown in
Table 409.
TABLE 409 SET GROUP COMMAND
Format Mode Function
set group
commander
ipport <0-63> ip-
pool < A. B. C.
D/M >
group config This sets a
command switch
Result: This sets a command switch; specify a layer 3
number for cluster management and sets IP address pool for
user cluster management.
f After a candidate switch is added to the cluster by
command switch and becomes a member switch,
Purpose
Steps
