ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
242 Confidential and Proprietary Information of ZTE CORPORATION
FIGURE 42 CLUSTER MANAGEMENT NETWORK
Public network
Independent switch
Candidate switch
NM console
110.1.1.1
TFTP Server
110.1.1.2
Command
switch
100.1.1.10
Cluster internal
network
Member
switch
Member switch
Member
switch
Member
switch
Member
switch
Outside the cluster
Cluster internal
address pool
192.168.1.0/24
Changeover rule of four roles of switches within a cluster is
shown in
