Chapter 4
Startup
4–9
or
Quick Start Procedure cont.
Configure I/O
Y
Configure
Input Mode? Y
Configure
Scanport? Y
If you answer NO to the Autotune
Torque & Velocity question, the follow-
ing configuration options will appear in
sequence as each configuration opera-
tion is completed
1. Configure I/O?
2. Configure Scanport?
3. Configure Input Mode?
4. Configure Pulse Input?
5. Configure MOP?
6. Configure Analog Input?
7. Configure Analog Output?
Use the SELect key to access the 2nd
line in any configuration display, and the
INC or DEC keys to make any changes.
When an option or enable operation is
complete, use the Enter key to save this
change.
When all tests and enable operations
have been completed, a Startup
Complete display will appear. Press the
Enter key to save all configuration data.
A Startup Completed display will
appear to indicate that the Quick Start
Procedure has been successfully
completed and saved.
If you wish to return to the Startup
sequence to make additional changes,
this can be accomplished from the
Startup Completed display. After
pressing the Enter key, use the INC or
DEC key to toggle to Reset Sequence.
Press the Enter key again and you can
now re–enter the Startup routine.
Startup Complete
Press ‘ENTER’
Configure
Pulse Input? Y
Configure
MOP? Y
Configure
Analog Input? Y
Configure
Analog Output? Y
Startup
Completed
Startup Reset Sequence
Startup
Completed
Reset
Sequence
or
To Next Page
