Allen-Bradley 1336 FORCE User Manual

Chapter 3
Programming Terminals
3–21
Keypad Description The GPT keyboard (Figure 3.5) is provided as either a 26 key version
(non–runtime) or 30 key (runtime version). The runtime version as
shown in Figure 3.6 provides additional Start, Stop, Jog and Direction
keys.
Figure 3.6
GPT Keypad
B
5
PRESET 1 PRESET 3
D
7
E
8
F
9
A
4
C
6
ALT PRESET 4
1
XREF 1
3
ESC
PRESET 5
2
PRESET 2
0
JOG
F1 F2 F3 F4
Start Key Stop Key
