Allen-Bradley 1336 FORCE User Manual

Chapter 2
Installation/Wiring
2–27
Figure 2.14.
Drive to Drive Hardware Connection
DRIVE 1
RTN
+15V
(Customer
Supplied)
120Ω
Isolator Board
Output
V+CHShdCL
V
–
J2
Input
V+CHShdCLV–
J1
24V 1A Max
(
PN 1336T – D2DIS)
.
.
1234
V +
5
.
.
C–H
C1 C2
Shd
8–18 VDC
Power Supply
PE
C–L V –
DRIVE 2
1234
V +
5
C–H Shd C–L V –
DRIVE 3
120Ω
1234
V +
5
C–H Shd C–L V –
To
TE
Bus
