Chapter 6
Troubleshooting
6–4
The first digit in the 5 character fault number for Standard Adapter Board
faults is always 2, indicating the source is an Adapter Processor:
0 = Velocity Processor (VP)
1 = Current Processor (CP)
2 = Adapter Processor (Standard Adapter or PLC Comm)
3 = Domino Processor (DP)
The Area Designator (2nd digit) and internal fault codes (last three digits)
remain the same as described under the Fault Code Definition on page 6–2.
Listed below are the fault codes for the Standard Adapter Board. For a
PLC Comm Adapter fault codes refer to the PLC Comm Adapter manual.
Table 6.B
1336 FORCE Standard Adapter Fault Descriptions
Fault # Description Type
24001
24002
24003
24004
24005
24006
24007
24017
24018
24019
24020
24021
24022
24024
24029
24030
24031
MBI Failure
BRAM Failure
VP Handshake Failure
CP Handshake Failure
VP Mode Failure
CP Mode Failure
SA Language Failure
SP Port 1 Failure
SP Port 2 Failure
SP Port 3 Failure
SP Port 4 Failure
SP Port 5 Failure
SP Port 6 Failure
4 – 20Ma Loss
Drive Type Difference
Illegal Drive Type
SP Internal Failure
Hard Fault
Hard Fault
Hard Fault
Hard Fault
Hard Fault
Hard Fault
Hard Fault
Fault/Warning/None
Fault/Warning/None
Fault/Warning/None
Fault/Warning/None
Fault/Warning/None
Fault/Warning/None
Fault/Warning/None
Soft Fault
Hard Fault
Soft Fault
Fault Text
HW Malfunction
HW Malfunction
SW Malfunction
SW Malfunction
SW Malfunction
SW Malfunction
HW Malfunction
SP PT1 Timeout
SP PT2 Timeout
SP PT3 Timeout
SP PT4 Timeout
SP PT5 Timeout
SP PT6 Timeout
4 – 20Ma Loss
Diff Drv Type
Illegal Drv Type
SW Malfunction
To Next Page
