Allen-Bradley 1336 FORCE User Manual

Chapter 2
Installation/Wiring
2–12
Table 2.A
Maximum Recommended AC Input Line Fuse Ratings (fuses are user supplied)
Drive Catalog
Number
kW (HP) Rating 200–240V
Rating
380–480V
Rating
500–600V
Rating
UL Class CC, T, J
1
– BS88 (non-UL installations)
1336T– _ _ F10 0.75 (1) 10A 6A –
1336T– _ _ F30 2.2 (3) 25A 15A –
1336T– _ _ F50 3.7 (5) 40A 20A –
1336T– _ _ 001 0.75 (1) 10A 6A 6A
1336T– _ _ 003 2.2 (3) 15A 10A 10A
1336T– _ _ 007 5.5 (7.5) 40A 20A 15A
1336T– _ _ 010 7.5 (10) 50A 30A 20A
1336T– _ _ 015 11 (15) 70A 35A 25A
1336T– _ _ 020 15 (20) 100A 45A 35A
1336T– _ _ 025 18.5 (25) 100A 60A 40A
1336T– _ _ 030 22 (30) 125A 70A 50A
1336T– _ _ 040 30 (40) 150A 80A 60A
1336T– _ _ 050 37 (50) 200A 100A 80A
1336T– _ _ X060 45 (60) – 100A –
1336T– _ _ 060 45 (60) 250A 125A 90A
1336T– _ _ 075 56 (75) – 150A 110A
1336T– _ _ 100 75 (100) – 200A 150A
1336T– _ _ 125 93 (125) – 250A 175A
1336T– _ _ X150 112 (150) – 250A –
1336T– _ _ 150 112 (150) – 300A 225A
1336T– _ _ 200 149 (200) – 400A 350A
1336T– _ _ 250 187 (250) – 450A 400A
1336T– _ _ X300 224 (300) – – 400A
Bussmann FWP/Gould Shawmut A–70C Semi–conductor Type
1336T– _ _ X250 187 (250) – 450A –
1336E– _ _ P250
2
187 (250) – 450A
2
–
1336T– _ _ 300T 224 (300) – 450A 400A
1336E– _ _ 300
2
224 (300) – 500A
2
450A
1336T– _ _ 350 261 (350) – 500A 450A
1336E– _ _ 350
2
261 (350) – 600A
2
1336T– _ _ 400 298 (400) – 600A 500A
1336E– _ _ 400
2
298 (400) – 600A
2
1336T– _ _ 450 336 (450) – 800A 600A
1336E– _ _ 450
2
336 (450) – 700A
2
600A
1336T– _ _ 500 373 (500) – 800A 800A
1336T– _ _ 600 448 (600) – 900A 800A
1336T– _ _ 650 485 (650) – – 800A
1336T– _ _ 700C
2
522 (700) – 600A
3
700A
3
1336T– _ _ 800C
2
597 (800) – 700A
3
700A
3
1 Both fast acting and slow blow are acceptable
2 Fuses are supplied with F and H Frame drives
3 Two fuses in parallel are required
